MDR-2000
V3
User's Reference Manual
Interactive Monitor
SET SITE -
This option allows a site number to be specified for the unit. The number is intended
for use with alarm applications which may elect
to
poll the unit after communications has been
established by the MDR-2000. When the alarm annunciation occurs the site number is the means
to
determine
in
which data files to store the collected information. Site numbers are used by the
telemanagement applications
to
distinguish data between PBX's. The number can be up to 2
characters long.
SET TANDEM
-This
option accepts either a 'Yes' or
'No'
as an argument.
If
'Yes' then the
ID
Type on the Originating ID will be converted from a
'T'
to a 'D'
on
tandem calls. Tandem calls are
defined as those calls which have an ID Type
of
'T'
for both the Originating ID and Terminating ID
fields. The default setting is
'No'.
SET THRESHOLD -
This option accepts a decimal value which is used to determine when the
MDR-2000 should raise a 'Buffer Full Alarm'. When the number
of
records in the unit reaches the
value then the MDR-2000 will initiate a call using the digits entered in the SET PRIMARY
PHONE and SET SECONDARY PHONE commands. The default setting is 'O'.
This alarm has the same format as PBX or external device generated alarms. The alarm code is
'M2KTH
R:
' with a message
of
'Storage Threshold Exceeded'. See the section on Alarm Annun-
ciation for more details on alarm messages.
SET TIME -
This option accepts the date in the form 'hhrnm'. The time is used by the MDR-2000
in
maintenance alarm messages.
SET XFER BLOCK -
Sets the number
of
records to be transmitted in a block in response to the
'X
B' command. The block size may be set from 1 to 255 records, the default
is
1.
5-14
