Specifications
Page 8
Outdoor unit
Dimension(W*D*H)
mm 770x300x555 770x300x555 720x270x495
inch 30.31x11.81x21.85 30.31x11.81x21.85 28.35x10.63x19.49
Packing (W*D*H)
mm 900x345x595 900x345x595 835x300x540
inch 35.43x13.58x23.43 35.43x13.58x23.43 32.87x11.81x21.26
Net/Gross weight
Kg 24.5/26.9 24.8/27 21.8/23.6
lbs. 54.01/59.30 54.67/59.52 48.06/52.03
Refrigerant type Kg R410A/0.5 R410A/0.53 R410A/0.65
Design pressure PSIG 550/340 550/340 550/340
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4”/3/8”) Φ6.35/Φ12.7(1/4"/1/2") Φ6.35/Φ12.7(1/4"/1/2")
Max. refrigerant pipe length
m 25 25 25
ft 82.02 82.02 82.02
Max. difference in level
m 10 10 10
ft 32.81 32.81 32.81
Connection wiring 16#x4 16#x4 16#x4
Plug type 14#x3/no-plug 14#x3/no-plug 14#x3/no-plug
Thermostat type Remote Control Remote Control Remote Control
Operation temperature 17-30 17-30 17-30
Ambient temperature
Indoor(cooling/ heating) °C 17-32/- 17-32/- 17-32/-
Outdoor(cooling/heating) °C -15-50/- -15-50/- -15-50/-
Qty’per 20’ /40’ /40’HQ 110/228/248 108/225/234 130/276/302
Notes:
1) Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C(80°F) DB /19.4 °C(67°F) WB Heating: - Indoor Temperature 21.1°C(70°F) DB / 15.6°C(60°F) WB
-Outdoor Temperature 35 °C(95°F) DB /23.9 °C(75°F) WB -Outdoor Temperature 8.3°C(47°F) DB / 6.1°C(43°F) WB
-Interconnecting Piping Length 7.5m - Interconnecting Piping Length 7.5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are net capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
