VC MAX VRF 50/60Hz
7
Part 1 - General Information
2.3 Outdoor Units
2.3.1 Single units
Table 1-2.4: Single outdoor unit appearance
8/10/12/14/16/18/20HP
(with single fan)
22/24/26/28/30HP
(with dual fans)
2.3.2 Combinations of units
Table 1-2.5: Combination outdoor unit appearance
32/34/36/38HP 40/42/44/46/48/50HP 52/54/56/58/60HP
62/64/66/68HP 70/72/74/76/78/80HP 82/84/86/88/90HP
