14
ME-MOVER.COM
3. You are now ready to mount the bars on the steering column! Firstly, ensure
the brake cables are threaded correctly as illustrated. The cables should be thread-
ed behind the bottle holder, through the cable loop on the steering column, and then
around the inner steerer below the stem as shown below.
4. Insert the stem onto the steerer. Make it
ush with the top of the steerer. Use the 4mm
hex key to tighten the screws. Do not over tighten.
Tighten to a no more than 5Nm.
WARNING!
Do not tighten the screws with more than 5Nm. 5Nm corresponds to a 20cm long
wrench with a force of 2.5kg.
NOTE: Lubricate the inner steerer with oil or grease.
NOTE: The left brake cable loops under
the stem from the left hand side. The
right brake cable loops under the stem
from the right hand side. This ensures
the cables are close to the frame; not
interfering with the riders knees whilst
riding.
