GB
22
ENGLISH
Example connection diagrams for KTF-3 (chime with power supply):
NAMEPLATE ILLUMINATION
This doorbell button is equipped with automatic nameplate illumination, which
turns on in darkness and turns o in brightness.
Note: If no power supply is connected, the doorbell button can still be used, only
the nameplate illumination will be non-functional.
KTF-1
KTF-2
KTF-3
