ENGLISH
REPLACING THE LABELLING FIELD
The labelling eld can be easily replaced. As shown in Fig. 1, carefully position a
suitable athead screwdriver at the side of the nameplate and gently pry it for-
ward without damaging the housing. Underneath is the labelling eld, which can
now be easily replaced.
DIMENSIONS FOR THE LABELLING FIELD
• KTF-1: 52mm x 57mm
• KTF-2: 52mm x 27mm (2x)
• KTF-3: 52mm x 17mm (3x)
TECHNICAL DATA
• Operating voltage: 8-12V AC or DC
• Power consumption: <1W
• Contact load capacity: max. 1A
• Protection class: IP44
• Temperature range: -20°C to +55°C
KTF-1
KTF-2
KTF-3
