Meade LX80 - Page 10

1(
Telescope Control Panel:
A. Power-On Lamp
B. 12v DC Power Connector
C. ON/OFF Switch
D. Handbox (HBX) Port
E. Aux 1
F. Aux 2
2$
Azimuth Adjustment Drive
2%
Latitude Adjustment Drive
2^
Latitude Lock
2&
Latitude Pivot Point
2(
RA Clutch
3!
Multi-Function Hex Head Tool
3@
Bubble Level
3&
AZ and EQ Home Position
3*
AZ Home reference point
3(
EQ Home reference point (Not Visible)
Figure 3: LX80 Control Panel - Detail
LX80 Key Features

A.

B.

C.

D.

E.

F.
2$
2%
2&
2(
3!
3@
3*
3&
3(
AudioStar #497 HANDBOX
LX80 Key Features
10
Figure 4: LX80 Controls
2^
1(
1(
