Meade LX80 - Page 12

2$
Azimuth Adjustment Drive
2%
Latitude Adjustment Drive
2^
Latitude Lock
2&
Latitude Pivot Point
3!
Multi-Function Hex Head Tool
LX80 Key Features
Adjustments for German EQ Mode
Fig 8: Azimuth Adjustment Fig 9: Latitude Adjustment
Fig 10: Latitude Pivot Point Fig 11: Latitude Lock Knob
Fig 7: Multi-Function Hex Head Tool
AudioStar #497 HANDBOX
LX80 Key Features
