2.2 CONNECT THE ELECTRONICS
Plug in servos and
LED module into ports
1, 2 and 3
Plug in
left foot motor
and right foot motor.
Make sure robot is in
robot mode
Left Foot Motor
Right Foot Motor
Well done, your
build is complete.
Turn robot on
Right Arm Servo
Left Arm Servo
Head LEDs
31
Plug in battery cable
23
24
25
26
