Mounting your Fiberglass or Cushion Seat
•Fiberglass Seats•
Fiberglass Seat - Turn your fi berglass seat over and remove any covers over the threaded studs.
Take your green fi berglass seat bracket and mount it to the bottom of the seat with the side with the
bend towards the front of the seat. Secure with four 1/4" hex nuts. Insert the 1/2 x 1-1/2 carriage bolt
through the brace and then through the L-shaped seat bracket. Secure with a 1/2" washer and hex
nut.
•Cushion Seats•
Cushion Seat - Slide the 1/2" x 1-1/2" carriage bolt through the bottom of the red seat bracket
before mounting the seat bracket to the seat. After placing the carriage bolt through the seat bracket,
place the seat bracket on the cushion seat. Secure with four 5/16" x 1" hex head bolts. Place the
seat on the L-shaped seat bracket and secure with a 1/2" washer and hex nut.
