1.3 Technical characteristics
1.4 Electrical diagrams
For electrical diagrams refer to FIG. (page...)
1.5 Area occupied by the operator
Under normal operating conditions and for optimal use of the machine's capacities, the operator
requires the area outlined in FIG.2.
Model Capacity
Lt
Speed
Rpm
Volt Power
Kw
Dimensions mm
A C B
Weight
Kg
MX20T
MX40T
MX60T
MX80T
MX20P/M
MX20P
MX40P/E
MX60P/E
MX80P/E
20
40
60
80
20
20
40
60
80
30/60/120
30/60/120
30/60/120
30/60/120
min.30 / max 120
min.30 / max 120
min.30 / max 120
min.30 / max 120
min.30 / max 120
400/50/3
400/50/3
400/50/3
400/50/3
230/50/1
400/50/3
400/50/3
400/50/3
400/50/3
1,1
1,3
1,7
1,7
0,75
0,75
2,2
3
3
700x500x1200
910x650x1520
1000x680x1600
1000x680x1600
700x500x1200
700x500x1200
910x610x1520
1000x680x1600
1000x680x1600
110
250
280
290
110
110
250
280
290
ENGLISH
FIG. 1
MX20
AC
B
MX40-60-80
AC
B
