Note: All packaging must be disposed of according to current legislation.
2.3 Electrical connection
The Y type connection of the machine to the electrical supply is made via the power supply
cable which is fitted with a plug only in the mono-phase version. For the machine with a three
phase supply, it is essential to mount a normalised and polarised plug at the end of the cable
(the distinction between phase and neutral must be unequivocal) and to verify that the direction
of rotation of the bowl is that indicated by the arrow found on the bowl.
2.4 Positioning of the machine
The electrical supply plug must be easily accessible and must not require the movement of
anything in order to access it. The distance between the machine and the electrical supply
must be such so as not to cause tension in the supply cable. Furthermore, the cable must not
be placed under the machine's support feet.
FIG. 3 FIG. 4
A
A
