Meco 3510PHW - Measurement Specifications; AC Current Measurement Specifications; DC Voltage Measurement Specifications; Resistance and Capacitance Specifications

3510PHW : 28-09-2012
6
7 8
5
AC Current : (50 to 400Hz) Trms
mA Trms : (AC+DC) (Burden Voltage : 5mV/mA) (50 to 400Hz)
2-5 Measurement Specifications :
Accuracy : ± (% of reading + number of digits) at 18
0
C to
28
0
C (64
0
F to 82
0
F) with relative humidity to 80%.
AC Voltage : (50 to 400Hz) Trms
Dimensions : 247 x 76 x 39 mm (approx.)
Weight : 465gms including battery
(approx.)
Accessories : Three phase adapter x 1,
Carrying Case x 1, Test leads
x 1, Battery (installed ) x 1, Pair
of alligator clip x 1, Instruction
manual x 1
Range Resolution Accuracy Sensitivity
Overload
Protection
99.99A 0.01A ±2% ±20dgts (50,60Hz) 0.10A
1000A
999.9A 0.1A ±4% ±20dgts (40-400Hz) 1.0A
Range Resolution Accuracy Sensitivity
Overload
Protection
99.99mA 0.01mA
±1% ±20dgts
0.20mA
600V
999.9mA 0.1mA 2.0mA
Range Resolution Accuracy Sensitivity
Overload
Protection
±1% ±20dgts (50,60Hz)
999.9mV 0.1mV
±2% ±20dgts (40-100Hz)
2.0mV
9.999V 0.001V 0.020V 600V
99.99V 0.01V
±1% ±20dgts (50,60Hz)
0.20V
600.0V 0.1V
±2% ±20dgts (40-400Hz)
2V
Input Impedance : 3MV
Resistance (Continuity <40V on the 999.9V range) :
Range Resolution Accuracy
Overload
Protection
999.9V 0.1V
9.999KV 0.001KV
±1% ±10dgts 600V
99.99KV 0.01KV
999.9V 0.1KV
MV :
Range Resolution Accuracy
Overload
Protection
9.999MV 0.001MV
99.99MV 0.01MV
±5% ±10dgts 600V
Capacitance :
Range Resolution Accuracy
Overload
Protection
10.000mF 0.001mF
100.00mF 0.01mF ±1.5% ±5dgts
600V
1000.0mF 0.1mF
7000mF1mF ±2.5% ±15dgts
DC Voltage :
Range Resolution Accuracy Sensitivity
Overload
Protection
999.9mV 0.1mV 2.0mV
9.999V 0.001V
±1% ±20dgts
0.020V
600V
99.99V 0.01V 0.20V
600.0V 0.1V 2V
Input Impedance : 3MV
PF & Phase Angle (50Hz, 60Hz) :
Range Resolution Accuracy Sensitivity
-60
0
/ 0
0
/ +60
0
0.1
0
±3.0
0
ACV>100V, ACA>10A
-0.5 / 1 / +0.5
Frequency :
Range Resolution Accuracy Sensitivity
40Hz/1KHz 0.1Hz ±0.5%rdg ±2dgts ACV>1.2V, ACA>6A
Diode (Continuity<40mV) :
Range Resolution Accuracy
Overload
Protection
2.000V 0.001V ±2% ±1dgts 600V
TRUE Power : (PF>0.5 or u <60
0
) (1hp = 0.7457kW)
Range Resolution Accuracy
Overload
Protection
60.00kW (<100A) 0.01kW ±5% +20 600VAC/
600.0kW (>100A) 0.1kW (50,60Hz) 1000AAC
Temperature (K-Type thermocouple) :
Range Resolution Accuracy
Overload
Protection
-50
0
C to 900
0
C 0.1
0
C ±1% ±1
0
C
30VAC or 60VDC
-58
0
F to 1000
0
F 0.1
0
F ±1% ±2
0
F
Horse Power : (PF>0.5 or u <60
0
) (1hp = 0.7457kW)
Range Resolution Accuracy
Overload
Protection
80.00HP (<100A) 0.01HP ±5% +20 600VAC/
800.0HP (>100A) 0.1HP (50,60Hz) 1000AAC
Apparent Power :
Range Resolution Accuracy
Overload
Protection
60.00KVA
(<100A)
0.01KVA
±2.5% ±20dgts 600VAC/1000AAC
600.0KVA
0.1KVA
(>100A)
