CONTROLS AND FUNCTIONS
On / Off Button
Intensity down
channel 1A and 2A
Intensity up channel
1A and 2A
Left channel socket 1A 2A
Mode button to change
from TENS, EMS and
Manual Adjustments
Programme selector
up and down
Intensity down
channel 1B and 2B
Intensity up channel
1B and 2B
LED charging indicator
Charging port
Red key lock button
Right channel socket 1B 2B
The set button is to select the desire parameters in manual mode only
it has no function when using the pre-set programmes.
