Tones
For all versions, a 5-way DIL switch selects the tone required. The settings for the standard tones are shown
in table 1 below:
Table 1
TONE
No.
TONE FREQ/DESCRIPTION
SWITCH
SETTING
12345
TONE
DESCRIPTION
Nominal SPL
(dB(A) @ 1M)
1
Alt Tones 800/970 Hz at 1/4 sec
11111
114
2
Sweeping 800/970 Hz at 7 Hz
11110
Fast Sweep (LF)
114
3*
Sweeping 800/970 Hz at 1 Hz
11101
Medium Sweep (LF)
114
4
Continuous at 2850 Hz
11100
109
5
Sweeping 2400-2850 Hz at 7 Hz
11011
Fast Sweep
114
6
Sweeping 2400-2850 Hz at 1 Hz
11010
114
7*
Slow Whoop
11001
Slow Whoop
115
8*
Sweep 1200-500 Hz at 1 Hz
11000
Din Tone
115
9
Alt Tones 2400/2850 Hz at 2 Hz
10111
111
10
Int Tone of 970 Hz at 1 Hz
10110
Back-up Alarm (LF)
114
11
Alt Tones 800/970 Hz at 7/8 Hz
10101
114
12
Int Tone at 2850 Hz at 1Hz
10100
Back-up Alarm (HF)
109
13
970 Hz at 1/4 sec on 1 sec off
10011
114
14
Continuous at 970 Hz
10010
114
15*
554 Hz for 0.1S/440 Hz for 0.4S
10001
French Fire Sound
101
16
Int 660 Hz 150 mS on 150 mS off
10000
Swedish Fire Alarm
106
17
Int 660 Hz 1.8 sec on 1.8 sec off
01111
Swedish Fire Alarm
106
18
Int 660 Hz 6.5 sec on 13 sec off
01110
Swedish Fire Alarm
104
19*
Continuous 660 Hz
01101
Swedish Fire Alarm
106
20*
Alt 554/440 Hz at 1 Hz
01100
Swedish Fire Alarm
100
21
Int 660 Hz at 7/8 Hz
01011
Swedish Fire Alarm
106
22
Int 2850 Hz 150 mS on 100 mS off
01010
Pelican Crossing
109
23
Sweep 800-970 Hz at 50 Hz
01001
Low Freq. Buzz
113
24
Sweep 2400 -2850 Hz at 50 Hz
01000
High Freq. Buzz
112
25
3x970 Hz pulses 0.5 off, 1.5 off
00111
113
26
3x2850 Hz pulses 0.5on/0.5off, 1.5 off
00110
109
27
Int 3100 Hz 0.32s on/0.68s off
00101
110
28
Spare / Customer special tone
00100
29
Spare / Customer special tone
00011
30
Spare / Customer special tone
00010
31
Spare / Customer special tone
00001
32
Spare / Customer special tone
00000
NOTE: If special tones were requested at the time of ordering, please see the separate tones list supplied
with the unit for details of these special tones and their respective switch settings.
* = EN54-3 Compliant Tones
