Medeli DD502 - MIDI Implementation Chart

MIDI Implementation Chart
Function... Transmitted Remarks
Basic Default 10 ch
Channel Changed X
Default X
Mode Messages X
Altered **************
Note 0 - 127
Number: True voice **************
Velocity Note on O 9n H, V = 1 - 127
Note off X (9 nH. V= 0)
After Key's X
Touch Channel's X
Pitch Bend X
Contro 0 X Bank Select
Change 1 X Modulation
5 X Portamento Time
6 X Data Entry
7 X Volume
10 X Pan
11 X Expression
64 X Sustain Pedal
65 X Portamento ON/OFF
66 X Sostenuto Pedal
67 X Soft Pedal
80 X Reverb Program
81 X Chorus Program
91 X Reverb Level
93 X Chorus Level
120 X All Sound OFF
121 X Reset All Controller
123 X All Notes OFF
Program X
Change: True # X
System Exclusive X
System : Song Position X
Common : Song Select X
: Tune X
System : Clock X
Real Time : Commands X
Aux : Local ON/OFF X
: All Notes OFF X
Messages : Active Sense X
: Reset X
O : YES
X : NO
