Mediastar 770 - Technical Specifications

Technical Specications
POWER INPUT
100 – 240 VAC, 2.2 – 1A, 50/60 Hz
200 Watts via a single IEC mains connector for single PSU 770 racks
200 Watts from either one of two IEC mains connectors for dual redundant 770-DR racks.
Mains supplies should be independent for full redundant operation.
ENCLOSURE POWER
DISSIPATION
200 watts maximum, dependent on the type of ‘blades’ tted
EXTERNAL LNB POWER DRAIN
FROM DVB-S2 ‘BLADES’
3A total
450mA per 774 or 784 DVB-S2 ‘blade’
DIMENSIONS 19” rack mounting, 3U high
WEIGHT
770:
3.6 Kg without processor modules
8.3 Kg with 9 processor modules
770-DR:
4.1 Kg without processor modules
8.3 Kg with 8 processor modules
ENVIRONMENTAL 0 – 40º C
APPROVALS FCC Part 15, CE, CB
