MEDIPIA Endoclean 2000 - Leakage Test Procedure

Leakage Test ProcessLeakage Test Process
 Put the testing SCOPE inside of Basin.
 Remove ETO cap and Connect
Leakage Tube with adapter.
 Set LEAKAGE and Push START button.
 Leakage testing water come into Basin from Leakage water Inlet
until SCOPE is sunk under water.
 Look at around the SCOPE carefully if there are bubbles.
 The water drain out of Basin in 2~3 minutes.
 After all the process finish, Push Air Emit Button for 1~2 second.
Olympus
Connector
Pentax
Connector
-16-
000 sec
000 min
000 sec
POGRAM PROCESS
MANUAL SELECTION
000 sec
LEAKAGE
WASH
AIR
DISINFECT
DISCHARGE
RETANK
ALCOHOL
DRAIN
BACK
(HOME)
ENTER
(SAVE)
START
STOP
SELECT
LEAKAGE
ENTER
(SAVE)
