Plug the micro-USB
power cable into
the micro-USB
POWER port of the
Connect
.
Plug the USB end
of the cable into an
AC adapter, TV, or
computer USB port.
Slide the ON/OFF switch of the
Connect
to the ON position.
Remove protective caps
from both ends of the
digital optical S/PDIF
audio cable
Plug digital optical
S/PDIF audio cable
into the OPTICAL
audio input of
the
Connect
.
Plug the other end into
the TV’s DIGITAL AUDIO
OUT (OPTICAL) port.
Plug 3.5 mm audio cable into the
3.5 mm audio input of the
Connect
.
Plug the other
end into the TV’s
headphone jack.
Headphone jack may be located on
rear, side, front, or bottom of TV.
ADJUSTING VOLUME
Choose
ONLY ONE
audio cable supported by your TV
STEP 2 STEP 3
STEP 1
STEP 4
SUBSEQUENT USE
A OFF ON
Hold the Multifunction button on the
Matrix3
for 3 seconds to power on.
1.
2.
1.
POWER ON AND CONNECT
CHOICE A: OPTICAL CHOICE B: 3.5 MM
CHOICE C: RCA
GETTING STARTED
CHARGE HEADPHONES
2.
3.
Proceed to
4.
Plug micro-USB
power cable into
the micro-USB
power port of the
Matrix3
.
Plug the USB end
of the cable into an
AC adapter, TV, or
computer USB port.
1.
2.
OR OR
1.
2.
3.
1.
2.
1.
2.
1.
2.
OPTICAL
DIGITAL AUDIO OUT
Plug red/white ends of RCA audio cable
into the TV’s red/white RCA AUDIO OUT
port.
Plug 3.5 mm end of RCA audio cable into
the 3.5 mm audio input of the
Connect
.
Change audio output settings to “VARIABLE”.
Set TV’s internal speakers to “OFF”.
**Exact menu and item names may vary
between TVs.
AUDIO OUT
R L
settings
sound / audio
Analog audio out
fixed
variable
settings
sound / audio
tv speakers
on
off
STEP 2
4.
If no solid blue light appears, perform the
pairing procedure below.
Otherwise, proceed to
STEP 3
A solid blue light will appear on the
transmitter to indicate that a connection
is established
Test for sound. Make sure the volume on both
your TV and headphones is turned up.
5.
4.
Proceed to
STEP 4
3.
Proceed to
STEP 4
Change Sound Output to “Optical”**
Change Digital Audio Output Format to
“STEREO” or “PCM”**
†
This may also need to done in the audio
output settings menu(s) of your streaming
app(s) and/or device(s) such as Apple TV
®
**Exact menu and item names may vary
between TVs.
†
On some TVs settings may be located in
“Advanced settings” or “Expert settings”
submenus.
1.
2.
settings
expert settings
Audio Output format
auto
dolby digital
pcm / stereo
DTS
settings
Sound / Audio
sound Output
hdmi
optical
tv speaker
NO SOUND? CHECK YOUR TV SETTINGS.
4.
Proceed to
STEP 4
Test for sound. Make sure the volume on
both your TV and headphones is turned up.
If you are using the Optical cable, you may
mute the TV speakers, which allows you to
directly control the volume on your
Bluetooth headphones.
Maximize the volume level on your TV, then
use volume controls on headphones to
adjust to preferred volume.
WHEN FINISHED, power off headphones
until next use
3.
Test for sound. Make sure the volume on
both your TV and headphones is turned up.
RCA jacks on TV must be designated
an AUDIO OUT. RCA input jacks,
commonly labeled AV IN, INPUT, or
COMP IN / COMPONENT will not work.
4.
3.
Proceed to
STEP 4
NO SOUND? CHECK YOUR TV SETTINGS.
3.
Proceed to
STEP 4
Volume max vol+
WHEN READY TO USE AGAIN, POWER ON THE
HEADPHONES AND THEY WILL RECONNECT
AUTOMATICALLY.
Do not put the Connect or your
headphones into pairing mode.
A solid blue light on the Connect will indicate
that a connection has been re-established.
COMPLETE ALL 4 STEPS. REMEMBER TO PLUG IN ONE POWER CABLE AND ONE AUDIO CABLE
NEED HELP?
VIEW OUR VIDEO SETUP GUIDE
Scan QR code or enter the URL
below into your web browser:
MEEaudio.com/ConnectVid
RCA
audio cable
Digital optical S/PDIF
audio cable
Micro-USB
power cable
MATRIX3 Bluetooth
Stereo
Headphones
CONNECT
Bluetooth
Transmitter
3.5mm
audio cable
PACKAGE CONTENTS:
MATRIX3
3
seconds
HOLD
B
A SOLID BLUE LIGHT ON TRANSMITTER
INDICATES CONNECTION
3
seconds
HOLD
TAP
to increase
volume
TAP
to decrease
volume
Tap the Volume Up or Volume Down
buttons on the
Matrix3
to adjust
headphone volume
Hold the Multifunction button on the
Matrix3
for 3 seconds to power off.
Put your Bluetooth headphones in pairing
mode. To put the Matrix3 in pairing mode,
hold the Power / Multifunction button for
about 5 seconds until the status indicator
light begins to flash red and blue and the
headphone says “Ready to Pair”.
Consult the user manual of your
Bluetooth headphones if you are not
sure how to put them in pairing mode
Once the headphones are in pairing mode,
click Pairing button “A” once to put the
Connect
in pairing mode.
A OFF ON
CLICK
PAIRING
BLINKING BLUE LIGHT
PAIRED
SOLID BLUE LIGHT
1.
2.
PAIR WITH BLUETOOTH HEADPHONES
3.
Proceed to
STEP 3
Blinking blue light will change to solid
blue light once successfully paired.
This procedure is used to re-pair the
Matrix3
or to pair a different headphone with the
Connect.
3.
Charge for 2 hours
2
hrs
The
Connect
and Matrix3 are paired and
ready to use and will connect automatically
once powered on.
