EN
20
23. Cooling n for IGBT
24. Cooling n holder
25. EMC
26. Fan
27. Cable deck seal
28. Power cord
29. Power switch
30. Air nipple
31. Fixed welding handle
32. Earth cable and clip
FIG. 1
• The product incorporates the latest IGBT
inverter technology and has smoother
welding characteristics than power sources
using traditional technology.
• The product can handle MIG/MAG and
hollow wire without shielding gas.
• The product can handle metal arc welding
(MMA) with direct current, with both
positive and negative electrodes.
• The product can be used for industrial
purposes.
• The product has very good arc stability for
MIG/MMA/TIG welding.
• The product has a stable design and metal
casing.
• The product has a xed MIG torch
connection.
• The product has variable welding voltage
for ne adjustment of welding
characteristics.
• The product has variable voltage and wire
feed control.
• The product has protection rating IP21S.
• The product is lightweight and convenient
to carry.
Voltage with
open circuit (V)
84 14 84
Min output
current (A)
10 10 30
Max output
current (A)
120 120 130
Max input current
(V)
24.8 14.9 20.5
Power source
eciency (%)
83 82 83
Standby
consumption (W)
20 20 20
DESCRIPTION
PRODUCT PARTS
1. Right cover
2. Handle cover
3. Handle
4. Spool
5. Support wall
6. Wire feeder
7. Hinge
8. Left cover
9. Lock
10. Control panel
11. Knob
12. Panel guard
13. Polarity conversion cable
14. Cable deck seal
15. Front cover
16. Quick-coupling
17. Foot
18. Insulation paper
19. Motherboard
20. Bottom casing
21. Cooling n for rectier diode
22. Cooling n holder
