• Do not connect an extension to the exhaust pipe.
• If an extension cable is required, a exible cable encased in heavy rubber must be used.
• Do not use extension cables that are too long: 60 m for cables with a diameter of 1.5 mm² and 100 m
for cables with a diameter of 2.5 mm².
• Do not place the generator near other electrical cables or lines, e.g. power lines in the national grid.
• The DC socket can be used when AC power is used. If both are used at the same time the total output
for AC and DC current must not be exceeded.
• The engines in most machines have a higher wattage than the rated power at startup.
TECHNICAL DATA
Generators
Rated voltage 230 VAC/50 Hz
Rated current 5 A
Rated speed 4,500 rpm
Rated output 1.6 kVA
Max. output 2.0 kVA
DC voltage 12 VDC/7.5 A
Phase Single-phase
Circuit breaker Microprocessor-based inverter control
Engine
Type Four-stroke
Engine displacement 105.7 cm³
Compression 8.5:1
Rated output 1.6 kW/5,500 rpm
Ignition system TCI
Spark plug NHSP LD A7RTC
Starting system Pull-start
Fuel Unleaded regular petrol
Lubricating oil SAE 10W30 (of API grade SG\SF)
Oil capacity 0.4 L
Dimensions and performance
Fuel tank capacity 3.6 L
Max. continuous operation at rated power 3.5 h
Sound pressure level, LpA 70 dB(A), K=3 dB
Measured sound power level, LwA 91 dB(A), K=3 dB
Guaranteed sound power level, LwA 92 dB(A), K=3 dB
Dimensions 531 x 310 x 445 mm
Weight 22 kg
Always use hearing protection!
