Mega H5 Hazer - Specifications; Mechanical Specifications; Electrical Specifications; Control & Programming

4
Specifications
Part Numbers
Fixture Flight Case
2005 - H5 Hazer 2005-RC Road Case
Mechanical Specifications
Fixture Flight Case for Shipping
Size: 22.12” x 13.25” x 11.12”
Weight: 31 lb
DMX Connectors: 3 and 5-pin XLR connectors
Power Connectors: Nema 5-15 cable mounted
Thermal: Maximum ambient temperature 110° F
Maximum surface temperature 140° F
Fastening System: Single mounting yoke
Display: Digital
Tank Capacity: 1/2 Gal
Electrical Specifications
Power supply: 110V AC 60Hz
Power consumption: Amps 14
Watts 1619
Heater: 1600 Watt
Haze Output: 10,000 Cuft/Min
Size: 25” x 16” x 15.5”
Weight: 26 lb
22.12”
11.12”
11”
Control & Programming
Protocol: DMX 512
Wireless Handheld Controller: Yes on/off
13.25” With Knobs
