Fig. 4
Fig. 5
Fig. 6
4. Place Bottom Stone (5), Side Stones (3),
Rear Stone (4) inside Firebox Assembly as
shown in Fig.4
5. Attach 2 pieces stone support brackets,
side (8) to Firebox Side Panel left and right
corner then tighten the 4 screws (A) as
shown in Fig.5
6. Re-attach the 2 screws which were
removed in Step 1, as shown in Fig.6
Assembly Instructions
8
3
3
4
5
8
To Next Page
