1. Loosen and remove the screws which were
pre-assembled, to separate firebox and Main
Lid as shown in Fig.1
2. Use 4 pieces screws (A), Top Stone front
support bracket (6), Top Stone rear support
bracket (7) to attach the Top Stone (2) to
main lid inside as shown in Fig.2
3. Tighten all the screws (A). As shown in Fig.3
Fig. 3
Assembly Instructions
Fig. 1
Fig. 2
6
2
7
7
To Next Page
