Megmeet MTC-08-NT - Page 54

54
set values and time of 1 ~ 4 segments of multiple segments. Table 6-1 set values and time
number of
segments
1
2
3
4
5
6
7
8
Setting
value(℃)
100.0
150.0
200.0
250.0
200.0
150.0
100.0
100.0
Time（s）
2
4
6
8
6
4
1
1
The beginning section of repetition is 3, the end section of repetition is 6, and the number of repeats is 3.
1. Refer to the 6.1 feature to change the first three steps for setting.
2. Select the control function and set it according to the figure below.
Figure 6-11 Setting control function
3.Select the Multi-step function and set it according to the following figure.
Figure 6-12 Set Multi-step function
