Megmeet MTC-08-NT User Manual

8
BFM
Contents
Remarks
nat
ure
Sa
ve
CH1/CH5
CH2/CH6
CH3/CH7
CH4/CH8
#736
Set value range error
address*6
0:normal
Other values:
setting the wrong
BFM address
R
N
#737
Cold junction
temperature*7
Default value：0
R
N
#738/#742
#739/#743
#740/#744
#741/#745
Work status word * 8
Default value：0
R
N
* 1. #701 ~ #708:The measured value of channel 1~l 8. The unit is determined according to the
input type (#901 ~ #908). When the mode is Celsius, the unit is 0.1 ℃ ; when the mode is
Fahrenheit, the unit is 0.1℉.
* 2. #709 ~ #716:Heating side control output value MV; #717 ~ #724: cooling hot side control
output value MV; The control output value of the channel obtained by the control algorithm.
* 3. #725 ~ #732: Each channel Multi-step setting executes the current segment. The segment
number being executed when multiple segment Settings are displayed. 0: indicates that the
execution state is not set in multiple segments or that multiple segments are completed.
* 4. #733: Output status of refrigeration end. Bit0 corresponds to the output state of the
refrigeration end of channel 1, Bit1 corresponds to the output state of the refrigeration end of
channel 2, and so on. When is 1, the output of the refrigeration end is effective; when is 0, the
output of the refrigeration end is invalid.
* 5. The failure status information of #735 is shown in table 1-6
Table 1-6 status information for BFM#735
A state of BFM#735
ON（1）
OFF（0）
b0：Error
When b1 ~ b15 any error occurs, this flag is 1
(b1 ~ b2 in any one of 1, stop all channel AD
converter)
Correct
b1：Save
－
－
b2：Hardware fault
AD converter or other hardware failure
Hardware normal
b3：Set value backup error
When the interference and the MTC due to an
internal error occurs, the flag will change
to 1. Then if you turn the power off, still
not be clear error, please contact the sales
agent or our
Data backup normal
b4：The cold end
temperature compensation
error
b5：AD transform digital
range errors
AD transform digital output value is less than -1
or greater than 4096, the flag is 1
Digital output value is
normal
b6：Set data recovery error
When the interference and the MTC due to an
internal error, if error reading backup data, the
flag is 1
－
b7：Save
－
－
b8～b15： Broken
accidentally detection (only
support thermocouple)
1 ~ 4 channel thermocouple broken
accidentally, the flag is 1
No broken
accidentally wrong
channel
