Product Specifications and Parts Lists
Rated Voltage
Rated Frequency
Input Power
Top Zone Temperature Control
110~120V
60Hz
130W
48°F ~ 53°F / 9°C ~ 12°C
E-2
Parts Lists
1. Top Zone Temperature Control Box
2. Top Zone Light Switch
3. Top Zone Light
4. Top Zone Fan Grill
5. Clapboard
7. Bottom Zone Light Switch
Bottom Zone Temperature Control
53°F ~ 64°F / 12°C ~ 18°C
8. Bottom Zone Light
9. Shelf
10. Bottom Zone Fan Grill
11. Hinge Cover
12. Glass Door
12
Glass Door
Hinge Cover
11
1
Top Zone Temperature
Control Box
2
Top Zone
Light Switch
3
Top Zone Light
4
Top Zone Fan Grill
5
Clapboard
7
Bottom Zone
Light Switch
8
Bottom Zone Light
9
Shelf
10
Bottom Zone
Fan Grill
Note: The actual cabinet temperature in a thermal electric unit is dependant on the ambient
room temperature. The above mentioned temperatures are approximations and based on an
average ambient room temperature of 77 °F or 25 °C.
Bottom Zone
Temperature Control Box
6
6. Bottom Temperature Control Box
