Meister basic BPMB 850 C - Scope of delivery; Technical information; Components

41
1 – Scope of delivery
•1 Rotary Hammer
•1 Depth stop
•1 Additional handle
•1 Flange key
• Operating Instructions
• Guarantee
2 – Technical information
Technical data
Power supply 230 V~/50 Hz
Rated power
requirement 850 W
Idle speed n
0
= 800 min
-1
Impact rate
(without load) 3600 min
-1
Max. drill diameter
- for concrete/stone/
granite 26 mm
Weight 4,0 kg
Mains cable 180 cm
Technical changes reserved.
Noise emission/vibration
L
PA
: 94,0 dB(A), L
WA
: 97,0 dB(A).
Hand/arm vibrations a
w
:
DRILL in cement:
– handle 22,7 m/s
2
,
– additional handle 13,2 m/s
2
,
CHISEL:
– handle 17,2 m/s
2
,
– additional handle 9,9 m/s
2
.
3 – Components
1 Drill chuck
1a Retaining sleeve
2 Depth stop
3 On/Off switch
4 On/Off switch for hammer operation
5 Selector switch DRILL/CHISEL
6 Additional handle
7 Gear grease filling hole
8 Flange key
Operating instructions & safety hints
To prevent injury, always read the operating instructions before use and
pass them on to any future owners of the tool. Keep with the tool.
GB
Page
1 – Scope of delivery 41
2 – Technical information 41
3 – Components 41
4 – Correct use 42
5 – General safety
instructions 42
6 – Safety instructions
relating specifically to
the equipment 44
Page
7 – Installation and setting 44
8 – Operation 45
9 – Mode of operation 45
10 – Maintenance and
environmental
protection 46
11 – Service instructions 46
Contents
