Melco D100 - Diagrams; Buttons and Ports

1
Diagrams
1
Power Button ( )
2
Power LED
Drive Tray
3
4
Eject Button ( )
5
Access LED
Steady blue: waiting
Steady green: reading
Steady red: writing
8
Power Connector
7
USB 3.0 Type-B Port for Connecting Digital Music Library and
Computer
6
USB 3.0 Type-A Port for Connecting Another USB Device
(available even when this device is off)
1 3 4 52
6
7 8
Buttons and Ports
D100-B
