ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
RESISTORS DIODES
R402 R3T181010J R,METAL OXIDE 1 OHM 1W or D511 D1VT001330 DIODE,SILICON 1SS133T-77
R3K581010J R,METAL OXIDE 1 OHM 1W ! D512 D1VT001330 DIODE,SILICON 1SS133T-77
R404 R63581010J R,FUSE 1 OHM 1W D513 D28T21DQN9 DIODE SCHOTTKY 21DQ09N-TA2B1
! R408 R4X5T6103F R,METAL 10K OHM 1/6W or D514 D1VT001330 DIODE,SILICON 1SS133T-77
R4T5T6103F R,METAL 10K OHM 1/6W D515 D1VT001330 DIODE,SILICON 1SS133T-77
! R409 R4X5T6563F R,METAL 56K OHM 1/6W or ! D516 D2MXN49370 DIODE,FAST RECOVERY 1N4937-PAN or
R4T5T6563F R,METAL 56K 0HM 1/6W D2WXN49370 DIODE SILICON 1N4937
! R429 R635813R9J R,FUSE 3.9 OHM 1W D517 D97U04R71B DIODE,ZENER MTZJ4.7B T-77
! R447 R3T28A151J R,METAL OXIDE 150 OHM 2W or D521 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
R3K58A151J R,METAL OXIDE 150 OHM 2W D522 D1VT001330 DIODE,SILICON 1SS133T-77
! R500 R0G3K2275K RC 2.7M OHM 1/2W D528 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
! R501 R5T2CD3R3J R,CEMENT 3.3 OHM 5W or D602 D97U08R21B DIODE,ZENER MTZJ8.2B T-77
R5X2CD3R3J R,CEMENT 3.3 OHM 5W D603 D1VT001330 DIODE,SILICON 1SS133T-77
! R508 R002T2221J RC 220 OHM 1/2W D604 D97U08R21B DIODE,ZENER MTZJ8.2B T-77
! R509 R002T4221J RC 220 OHM 1/4W D606 D2MXN40020 DIODE,FAST RECOVERY 1N4002-PAN or
! R514 R63581R22J R,FUSE 0.22 OHM 1W D2WT011E10 DIODE SILICON 11E1-EIC
! R515 R002T2124J RC 120K OHM 1/2W
ICS
! R517 R3T1811R5J R,METAL OXIDE 1.5 OHM 1W IC101 I56F07091B IC OEC7091B
! R518 R4X5T6562F R,METAL 5.6K OHM 1/6W or IC199 A3R101Q015 INIT DATA
R4T5T6562F R,METAL 5.6K OHM 1/6W ! IC401 I03TD804N0 IC LA78040N-E
! R519 R002T4102J RC 1K OHM 1/4W ! IC501 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
! R538 R002T2155J RC 1.5M OHM 1/2W IC1001 I01DP75110 IC AN7511
! R542 R3T181R47J R,METAL OXIDE 0.47 OHM 1W or
TRANSISTORS
R3K581R47J R,METAL OXIDE 0.47 OHM 1W ! Q401 TD3Q021400 TRANSISTOR SILICON TT2140LS-YBC11
! R629 R3T28B220J R,METAL OXIDE 22 OHM 3W or ! Q402 TC5T01627Y TRANSISTOR SILICON 2SC1627_Y(TPE2)
R3K58B220J R,METAL OXIDE 22 OHM 3W ! Q501 T25F035630 FET
2SK3563(ORION_Q)
! R803 R3T28A123J R,METAL OXIDE 12K OHM 2W ! Q502 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)
! R805 R3T28A123J R,METAL OXIDE 12K OHM 2W Q507 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)
! R807 R3T28A123J R,METAL OXIDE 12K OHM 2W Q601 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT
CAPACITORS
Q602 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT
C402 E5EZFB101M CE 100 UF 160V Q603 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT
! C403 E02LT4471M CE 470 UF 35V Q606 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT
! C414 E02LU4101M CE 100 UF 35V Q607 TCATC31980 TRANSISTOR,SILICON
KTC3198-AT(Y,GR)
! C418 E02LT3471M CE 470 UF 25V ! Q801 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC
! C434 E02LU8220M CE 22 UF 100V ! Q802 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC
C437 P4J7F3334J CMPP 0.33 UF 250V PMS ! Q803 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC
! C443 P4G8FJ722H CMPP 0.0072UF 1.25KV PHE
COILS &TRANSFORMERS
! C446 E02LU5220M CE 22 UF 50V L001 02167F3R3J COIL 3.3 UH
! C503 C0JTB0513K CC 0.001 UF 500V B L101 02167F3R3J COIL 3.3 UH
! C505 P2122B334M CMP
0.33 UF 275V ECQUL ! L501 029X000417 COIL,LINE FILTER SS11V-10062-CH
! C506 CC3LE0ML3M CC 0.0033UF 250V ! L503 028R200031 COIL,DEGAUSS 8R200031
! C508 CC3LE0MH3M CC 0.0022UF 250V L801 021673101K COIL 100 UH
C514 C0PLRR7W2K CC 820 PF 2KV RR T401 045011001L TRANS,HORIZONTAL DRIVE STP-03Q24
C517 C0PLRR7W2K CC 820 PF 2KV RR ! T502 048129109S TRANSFORMER,SWITCHING 8129109S
! C519 E02LT2102M CE 1000 UF 16V
JACKS
C521 E5EZFB101M CE 100 UF 160V J702 060Q401077 RCA JACK AV1-09D-3
! C526 E02LFC221M CE 220 UF 200V J703 060Q401076 RCA JACK AV1-09D-4
! C801 CHGTB04L2K CC 330 PF 50V B ! J801 066F120018 SOCKET,CATHODE RAY TUBE ISMS01S
C819 C0JBB0713K CC 0.001 UF 2KV B
SWITCHES
DIODES
SW101 0504101T34 SWITCH,TACT EVQ21505R
D001 D97U03301B DIODE,ZENER MTZJ33B T-77 SW102 0504101T34 SWITCH,TACT EVQ21505R
D403 D2MXN40020 DIODE,FAST RECOVERY 1N4002-PAN or SW103 0504101T34 SWITCH,TACT EVQ21505R
D2WT011E10 DIODE SILICON 11E1-EIC SW104 0504101T34 SWITCH,TACT EVQ21505R
D404 D97U06R21B DIODE,ZENER MTZJ6.2B T-77 SW105 0504101T34 SWITCH,TACT EVQ21505R
! D405 D2MXN49370 DIODE,FAST RECOVERY 1N4937-PAN or
P.C.BOARD ASSEMBLIES
D2WTAU02A0 DIODE SILICON AU02A-EIC PCB010 A3R107Q010 PCB ASS'Y TMD604A
D406 D2MXN40020 DIODE,FAST RECOVERY 1N4002-PAN or PCB110 A3R101Q110 PCB ASS'Y TCD460A
D2WT011E10 DIODE SILICON 11E1-EIC
MISCELLANEOUS
D408 D2MXN40020 DIODE,FAST RECOVERY 1N4002-PAN or B501 024HT03553 CORE,BEADS W5RH3.5X5X1.0
D2WT011E10 DIODE SILICON 11E1-EIC B504 024HT03553 CORE,BEADS W5RH3.5X5X1.0
D409 D2MXN40020 DIODE,FAST RECOVERY 1N4002-PAN or ! CD501 1209414909 CORD AC BUSH 9414909 or
D2WT011E10 DIODE SILICON 11E1-EIC 120R414903 CORD AC BUSH 0R414903
! D410 D2MXN49370 DIODE,FAST RECOVERY 1N4937-PAN or CD801 06CU012401 CORD CONNECTOR CU012401
D2WTAU02A0 DIODE SILICON AU02A-EIC CD802 WCL6848038 FLAT CABLE AWM2468
AWG26 5C GRAY 480MM
! D411 D2MXN49370 DIODE,FAST RECOVERY 1N4937-PAN or ! CP401 069S450089 CONNECTOR PCB SIDE A1561WV2-A5P
D2WTAU02A0 DIODE SILICON AU02A-EIC ! CP502 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
! D412 D97U05R11B DIODE,ZENER MTZJ5.1B T-77 CP601 0694260139 CONNECTOR PCB SIDE 173979-6
! D501 D2WXN40050 DIODE SILICON 1N4005-EIC CP801 069D01001A CONNECTOR PCB SIDE 003P-2100
! D502 D2WXN40050 DIODE SILICON 1N4005-EIC CD101A 06CH012002 CORD CONNECTOR CH012002
! D503 D2WXN40050 DIODE SILICON 1N4005-EIC CD101B 06CH012003 CORD CONNECTOR CH012003
! D504 D2WXN40050 DIODE SILICON 1N4005-EIC CP802A 067U005049 WIRE HOLDER B2013H02-5P
! D505 D28T21DQN9 DIODE SCHOTTKY 21DQ09N-TA2B1 CP802B 067U005049 WIRE HOLDER B2013H02-5P
D506 D97U01801B DIODE,ZENER MTZJ18B T-77 CP803A 067U003029 WIRE HOLDER B2013H02-3P
D507 D97U03R61B DIODE,ZENER MTZJ3.6B T-77 CP803B 067U003029 WIRE HOLDER B2013H02-3P
D508 D1VT001330 DIODE,SILICON 1SS133T-77 ! F501 081PC04005 FUSE 51MS040L
! D509 D97U01801B DIODE,ZENER MTZJ18B T-77 ! FB401 043219018Y TRANSFORMER,FLYBACK BSC23-N0148
! D510 D2WXRU2AM0 DIODE SILICON RU2AM-EIC FH501 06710T0009 HOLDER,FUSE EYF-52BCY
