1. Disc Tray
2. OPEN/CLOSE Button
3. Remote Sensor
4. Remote Receive Indicator
5. STANDBY Indicator
6. POWER ON Indicator
7. STANDBY/STOP Button
To return to the Standby mode while the unit is on, press and hold the STANDBY/STOP button for
two seconds then release; the unit will be turned off and the Standby indicator will light on.
8. PLAY (®) Button
6
LOCATION OF CONTROLS
FRONT
1. AC Power Cord
2. Stereo Audio Left/Right Output Jacks
3. Video Output Jack
4. S-Video Output Jack
5. Coaxial Digital Audio Output Jack
6. PROGRESSIVE SCAN ON/OFF Switch
7. Component Video (Y, P
B, PR) Output Jacks
REAR
