PARTS LIST
For service regarding parts, assembly or warranty information, please call: 1-800-459-4409.
The keys are taped to bottom
left drawer of the chest.
3
9
8
7
2
5
4
6
10
11
12
1
Ref# Description Part# Qty
1 Gas Strut 303186 2 pcs
2 Grommet 314027 1 pc
3 Power Strip 333059 1 pc
4 Lock and Key
(1201–1210)
304054 1 pc
5 Slide Set 1 300176 –
300177
8 sets
6 Slide Set 2 300040–
300042
1 set
7 Drawer Liner 551900 4 pcs
8 Drawer Liner 551887 4 pcs
9 Till Liner 551886 1 pc
10 Connector 200837 2 pcs
11 Chest Handle 306001 2 pcs
12 M6 x 12 Hex Bolt 321051 10 pcs
The keys are taped to the top of the
caster carton, which is placed in
the bottom drawer of the cabinet.
12
1
2
3
4
6
5
8
9
10
7
13
15
14
Ref# Description Part# Qty
1 Cabinet Handle 306061 1 pc
2 M6 x 12 Hex Bolt 321051 4 pcs
3 Grommet 314027 1 pc
4 Power Strip 333059 1 pc
5 M6 x 12 Phillips
Head Bolt
320323 2 pcs
6 Cord Wrap 236870 1 pc
7 Slide Set 300176 –
300177
14 sets
8 Swivel Caster 302177 2 pcs
9 Washer 324002 16 pcs
10 M8 x 25 Hex Bolt 321047 16 pcs
11 Drawer Liner 551900 5 pcs
12 Drawer Liner 551887 5 pcs
13 Rigid Caster 302001 2 pcs
14 Lock and Key
(1201–1210)
304054 1 pc
15 Drawer Liner 551889 1 pc
NOTE:
1. Replacement keys may be ordered,
using the required code which appears
on the face of the lock.
2. Give the information for service parts:
part number and quantity.
To Next Page
