Hi-Hat Stand:
17. Fold the Hi-Hat Pedal (W) down and loosen the hi-hat stand leg wing nut. Extend the 3 hi-hat stand legs
(X) out so that the black pedal brace support (Y) is approximately 1 inch o of the oor. Unscrew the pedal
holding peg (Z) from the boom of the brace support, line up the holes from pedal base, reinsert the hold-
ing peg and secure with the bolt.
18. Remove the Hi-Hat clutch (a) by loosening the wing nut and pulling it up o of the hi-hat stand drive sha
(b). Place 1 of the Hi-Hat cymbals, concave side up, on top of the felt pad, metal washer and saddle (c).
The adjustment screw on the boom of the saddle adjusts the lt of the high hat.
Drum Throne, AKA Stool:
19. Open the drum throne base (d) so that the three legs are extended fully and at on the oor. Insert the
seat post into the block underneath the throne top (e) and secure. Adjust sing height and secure.
20. Once seated, you can now bring the set together and fully adjust any heights and angles of the drums,
cymbal, and stands to your liking. Enjoy!
