Mepla Alfit Soft-close - Page 13

CS 07 Mirro 15° negative Hinge
Page 1.5.58
CS 07 Mirro Hinge
Page 1.5.56
PU = Packing unit
Soft-close® Mirro
Technical Information
The installing of our furniture fittings must comply
with the Mepla-Alfit instructions that are stated in our
available sales brochures, otherwise Mepla-Alfit can’t
be held liable. If further information on installation and
assembly is needed, please contact one of our factories
directly.
Thank you for your understanding.
Position for Soft-close® Mirro
Position for additionalSoft-close® Mirro
(recommended)
50 pcs.
924.200.38.0215
PU
Ref. No.
Soft-close® Mirrro
with Mirro -15° hinge
Soft-close®Mirro
with Mirro hinge
Drawing with mounting plate, thickness 02
For CS 07 Mirro and CS 07 Mirro 15° negative angle hinges
Soft-close
®
Mirro
1.5.13
Soft-close®
