Mepla Alfit Soft-close - Page 15

1.5.15
Technical Information
Soft-close®
00
9
10 11
x x x
x x x
x x x
(TA) 4 mmHinge Cranking 00
(K)
9 10 11
x x x
x x x
x x x
(TA) 5 mm
(K)
9 10 11
x x x
x x x
x x x
(TA) 6 mm
(K)
Mounting plate
thickness (f)
02
04
00
4
x
x
x
(TA) 4 mmHinge Cranking 08
(K)
4
x
x
x
(TA) 5 mm
(K)
4
x
x
x
(TA) 6 mm
(K)
Mounting plate
thickness (f)
02
04
00
4
x
x
x
(TA) 4 mmHinge Cranking 15
(K)
4
x
x
x
(TA) 5 mm
(K)
4
x
x
x
(TA) 6 mm
(K)
Mounting plate
thickness (f)
02
04
Recommended position for Soft-close® ACC
g = s + m
Values based on door edge 1 mm radius. We recommend a trial mount.
When using wooden frames smaller than 60 mm we recommend a trial mount.
When using aluminium frames use of glass gasket or Silicon is not allowed in
the area where Soft-close ACC is fitted.
* Position for inset door:
10,5 mm + door thickness + 2 mm
*
