420
Practical hints
Replacing bulbs
Replacing bulbs for rear lamps
Before you start to replace a bulb for a rear
lamp, do the following first:
왘 Turn the exterior lamp switch to
position M (
컄 page 122).
Tail lamp unit
왘 Open trunk lid.
왘 Swing the trim panel covering the cor-
responding rear lights to the side.
1 Tab
왘 Press tabs 1 together.
왘 Remove the bulb carrier.
왘 Press gently onto the respective bulb
and turn counterclockwise out of its
bulb socket.
왘 Press the new bulb gently into its bulb
socket and turn clockwise until it
engages.
1 Brake lamp
2 Turn signal lamp
3 Backup lamp
4 Standing and side marker lamp
5 Rear fog lamp (driver’s side)/tail
왘 Reinstall the bulb carrier.
Let tabs 1 engage.
왘 Reinstall trim panel.
License plate lamp
1 Screws
왘 Loosen both screws 1.
왘 Remove the license plate lamp.
왘 Replace the tubular lamp.
왘 Reinstall the license plate lamp.
왘 Retighten the screws 1.
