326
Controls in detail
Useful features
1 Retainer pin
2 Eyelet
Removing
왘 Pull floormat off of retainer pins 1.
왘 Remove the floormat.
Installing
왘 Lay down the floormat in the respective
footwell.
왘 Press the floormat eyelets 2 onto re-
tainer pins 1.
Seat cover under third-row seats
If something falls under the third-row
seats, you can remove the seat cover in
order to reach under the seats.
Removing seat cover
Example passenger side
왘 Fold the respective seat halfway in or
out (
컄 page 305).
왘 Reach into the recess in the seat cover.
왘 Pull the seat cover in the direction of
the arrow.
Remove the seat cover to reach under
the seats.
Installing seat cover
왘 Fold the seat halfway in or out
(
컄 page 305).
왘 Put the seat cover back into place
using the guide pins.
왘 Press the seat cover down until it
engages.
왘 Make sure that the seat cover is
engaged properly by folding the seat all
the way in and out.
164.boo Seite 326 Freitag, 30. März 2007 12:54 12
