Instrument Display overview
Mercedes-AMG vehicles: be sure to observe
the notes in the Supplement. Otherwise, you
may fail to recognize dangers.
&
WARNING Risk of accident due to an
instrument display malfunction
If the Instrument Display has failed or mal‐
functioned, you may not recognize function
restrictions applying to safety relevant sys‐
tems.
The operating safety of your vehicle may be
impaired.
#
Drive on carefully.
#
Have the vehicle checked immediately
at a qualified specialist workshop.
If the operating safety of your vehicle is
impaired, park the vehicle immediately and
safely. Contact a qualified specialist workshop.
Instrument Display (standard)
1
Speedometer
2
Multifunction display
3
Tachometer
4
Coolant temperature gauge
5
Fuel level and fuel filler flap location indica‐
tor
Instrument Display in the Widescreen Cock‐
pit
1
Speedometer
2
Multifunction display
3
Example: area for additional values
4
Coolant temperature gauge
5
Fuel level and fuel filler flap location indica‐
tor
%
Further display content can be shown on dis‐
play 3 for additional values (/ page 233).
The segments in speedometer 1 indicate the
status of the following systems:
R
Cruise control (/ page 182)
230
Instrument Display and on-board computer
