Mercedes-Benz Wallbox Home User Manual

12
Appendix
Technical specifications
Model variant A0009067408 A0009067508
Compliance IEC 61851-1 / 61439-7
Power supply for supply cable sizes of up to 5 x 16 mm² for supply cable sizes of up to 3 x 16 mm²
Rated voltage 230 / 400 V 230 V
Rated current 32 A, single or 3-phase 32 A, single phase
Rated frequency 50 Hz
Max. output 22 kW 7.2 kW
Charging connection Fixed charging cable with charging plug according to IEC 62196-2 Type 2, ca. 6 m
Circuit-protection devices Type A 30 mA RCCB and DC-RCM, I
Δn d.c.
electronic DC fault current detection ≥ 6 mA
Control / Customization
Internal RS485 interface (interface for external load management,
no access for users/installation technicians)
Upstream fuse C characteristic MCB, rated current according to power supply and Wallbox setting but no more than 32 A
Factory setting for maximum charging current 16 A 32 A
PE system TN-S
Operating temperature -30 to 50°C
Storage temperature -30 to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Overvoltage category III
Degree of pollution 3
Rated insulation voltage (U
i
) 4kV
Rated impulse voltage (U
imp
) 4kV
Rated peak withstand current (I
pk
) 6kA
Rated short-time withstand current (I
cw
) 5kA
Rated conditional short-circuit current (I
cc
) 6/10 kA (C tripping characteristic)
Rated diversity factor (RDF) 1.0
Degree of protection (housing) IP 55
Impact strength IK08
Dimensions (housing) 438 x 328 x 170 mm (H x W x D)
Maximum elevation ≤ 2,000 m AMSL (above mean sea level)
Weight per unit (net) ca. 8.5 kg
Weight per unit (gross) ca. 10 kg
