Trip odometer
Registers the kilometers (miles) of individual journeys.
• Standard analog instrument
cluster
To reset, press and hold the control
for one second.
• Optional electronic instrument
cluster
Refer to Electronic Message Center
in the Driver controls chapter for
information on how to switch the
display from Trip 1 and Trip 2
features on the electronic
instrument cluster.
Tachometer
Indicates the engine speed in revolutions per minute.
Driving with your tachometer pointer continuously at the top of the scale
may damage the engine.
• Standard analog instrument
cluster
• Optional electronic instrument
cluster
TRIP A
CRUISE
MPH
km/h
km
0
1
2
3
4
5
6
78
X 1000
RPM
TRIP 1
TRIP 2
RPM x 1000
0
1
2
3
4
5
6
7
8
CRUISE
MPH
km/h
km
0
1
2
3
4
5
6
78
X 1000
RPM
TRIP 1
TRIP 2
Instrument Cluster
19
