Mercury 2004 Marauder User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
16 — Not used
17 — Not used
18 — Not used
19 15A* Powertrain Control Module
(PCM), Fuel injectors
20 15A* PCM, HEGOs
21 — Not used
22 — Not used
23 — Not used
24 — Not used
101 30A** Ignition switch, Starter motor
solenoid via starter relay, IP fuses
7, 9, 12 and 14
102 50A** Cooling fan (engine)
103 40A** Blower motor
104 40A** Heated backlight relay
105 30A** PCM power relay, Diagnostic
connector, PDB fuses 19 and 20,
A/C clutch relay, Fuel pump
module relay
106 40A** Anti-lock Brake System (ABS)
107 — Not used
108 — Not used
109 — Not used
110 — Not used
111 — Not used
112 50A** Ignition switch feed to IP fuses 4,
6, 8, 11, 13, 15, 17, 20, 22 and 28
113 50A** Feeds IP fuses 3, 5, 21, 23, 25, 27
114 30A** VAP Steering, Air suspension
compressor, Instrument cluster
2004 Marauder (mdr)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
137
