Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
115 50A** Ignition switch feed to IP fuses 16
and 18
116 30A** Wipers
117 – Not used
118 20A** ABS
201 1/2 ISO Horn relay
202 1/2 ISO PCM relay
203 1/2 ISO Fuel pump relay
204 1/2 ISO A/C clutch relay
205 1/2 ISO Traction control switch relay
206 — Not used
207 1/2 ISO Fog lamp relay
208 1/2 ISO Moonroof relay
209 1/2 ISO Hi-beam disable with fog lamp
relay
301 Full ISO Blower motor relay
302 Full ISO Starter solenoid relay
303 Full ISO Air suspension relay
304 Full ISO Heated backlight relay
401 — Not used
501 Diode PCM diode
502 Diode A/C clutch
503 — Not used
601 — Not used
602 20A** Adjustable pedals, Power seat,
Locks, Decklid, Lumbar
* Mini fuse ** Circuit breaker/Maxi fuse
Relays
Relays are located in the power distribution box and should be replaced
by qualified technicians.
2004 Marauder (mdr)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
138
