Fuse/relay
location
Fuse amp
rating
Power distribution box description
18 10A* (Vulcan
engine only)
A/C clutch relay, PCM keep alive power
— (Duratec
engine only)
Not used
19 — Not used
20 — Not used
21 — Not used
22 5A* (Vulcan
engine only)
Heated PCV valve
10A*
(Duratec
engine only)
A/C clutch relay, PCM keep alive power
23 — Starter motor relay
24 — Fan relay
25 — Wiper speed relay
26 10A* Alternator
27 5A* Rear control unit, Antenna
28 15A* HEGO sensor, Transmission shift solenoid,
Canister vent, A/C clutch relay
29 — Wiper park relay
30 — Fuel pump relay
31 — PCM power relay
32 — Fan relay
33 — A/C clutch relay
* - Mini Fuses ** - Maxi Fuses CB - Circuit breaker
Relays
Relays are located in the power distribution box and should be replaced
by qualified technicians.
REVIEW COPY
2005 Sable (sab), Owners Guide (post-2002-fmt) (own2002),
Market: USA_English (fus)
Roadside Emergencies
181
