Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
36 5A PATS module
37 10A Climate control
38 20A Subwoofer (Audiophile radio)
39 20A Radio
40 20A Spare
41 15A Mic mirror, Moon roof, Front lock
switches, Radio
42 10A Spare
43 10A Spare
44 10A Spare
45 5A Relay coils: PDB, Auxiliary A/C, Front
and rear wipers, Front blower motor
46 7.5A Occupant Classification Sensor (OCS),
Passenger Airbag Deactivation
Indicator (PADI)
47 30A Circuit
Breaker
Power windows
48 — Delayed accessory relay
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
Always disconnect the battery before servicing high current
fuses.
To reduce risk of electrical shock, always replace the cover to
the Power Distribution Box before reconnecting the battery or
refilling fluid reservoirs.
If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Specifications chapter.
2008 Sable (mgo)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
250
