Mercury 2008 Sable User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
16 20A** Power point (console)
17 10A** Alternator
18 — Not used
19 — Not used
20 40A* Rear defroster
21 30A* Power seat motors (passenger)
22 20A* Heated seat module
23 10A** PCM Keep alive power, Canister vent
24 10A** A/C clutch relay
25 25A Spare
26 20A** Backup relay
27 15A** Fuel relay (Fuel pump driver module,
Fuel pump)
28 — Not used
29 30A Spare
30 — Not used
31 30A* Spare
32 30A* Driver seat motors, Memory module
33 20A* Ignition switch (to SJB)
34 — Not used
35 40A* Front A/C blower motor
36 1A Diode One-touch start
37 1A Diode Fuel pump
38 10A** IVD, Yaw rate sensor
39 10A** Fuel diode, PCM
40 — Not used
41 G8VA relay A/C clutch
42 G8VA relay Fuel pump
43 G8VA relay Backup
44 — Not used
2008 Sable (mgo)
Owners Guide (post-2002-fmt)
USA (fus)
