Replacing front sidemarker bulb
1. Make sure the headlamp control
is in the off position.
2. Reach under the side of the front
fascia to access the bulb sockets
and connectors.
3. Remove the bulb socket by
rotating it counterclockwise, then
pulling it out of the lamp assembly.
4. Pull the bulb straight from the
socket.
Install new bulb in reverse order.
Replacing rear stop/tail/turn signal/backup lamp bulbs
The stop/tail/turn signal/backup lamp bulbs are located in the tail lamp
assembly. Follow the same steps to replace either bulb.
Note: Your vehicle is equipped with a stop/tail lamp assembly containing
integral multiple light emitting diodes (LED). If replacement is required,
see your authorized dealer.
• (1) Backup lamp
• (2) Turn signal lamp
• (3) Stop/tail lamp (LED)
1. Make sure the headlamp switch is in the off position and open the
trunk.
1
2
3
2009 Sable (mgo)
Owners Guide, 1st Printing
USA (fus)
Lights
91
