2. Remove the press pin and cargo
net fastener. Carefully pull the
carpet away to expose the backside
of the tail lamp assembly.
3. Remove the nut and washer
assemblies, then pull the lamp
assembly away from the vehicle.
4. Remove the bulb socket by
rotating it counterclockwise, then
pulling it out of the lamp assembly.
5. Pull the bulb straight from the
socket.
Install new bulb(s) in reverse order.
Replacing brake and tail lamp bulbs
These must be replaced by your authorized dealer.
Replacing high-mount brake lamp bulbs
This must be replaced by your authorized dealer.
Replacing license plate lamp bulbs
1. Make sure the headlamp switch is
in the off position.
2. Remove the two screws from the
license plate lamp assembly.
3. Remove bulb socket by turning
counterclockwise.
4. Carefully pull the bulb out from
the socket.
Install new bulb(s) in reverse order.
2009 Sable (mgo)
Owners Guide, 1st Printing
USA (fus)
Lights
92
