Mercury 25M User Manual

GENERAL INFORMATION
33
1 - Tilt handle
2 - Upper cowl
3 - Water pump indicator hole
4 - Water plug
5 - Reverse Lock Lever
6 - Drive shaft housing
7 - Anti‑ventilation plate
8 - Trim tab
9 - Secondary water intake
10 - Propeller
11 - Starter rope handle
12 - Shift lever
13 - Clamp screw
14 - Clamp bracket
15 - Trim position pin
16 - Battery cable
17 - Upper oil plug
18 - Cooling water intake
19 - Lower oil plug
20 - Connector B
21 - Remote control box
22 - Main switch
23 - Stop switch
24 - Cord assembly
25 - Fuel tank
26 - Primer valve
27 - Fuel connector
28 - Fuel tank cap
29 - Air vent screw
30 - Fuel Pick Up Elbow
