INSTALLATION
46
The steering link rod parts are available and assembled as
illustrated below. Spacers may or may not be required depending
on cable brands.
a - Grease
b - Spacer (option)
c - Bolt
d - Washer B
e - Cushion rubber
f - Spring
g - Spacer
h - Collar
i - Nut lock
j - Rod
k - Washer A
l - Seal ring
Battery Installation
MOUNTING BATTERY
Follow the battery manufacturer's instructions carefully. Mount
battery securely to the hull in a place free from splashing water.
NOTE: Electric starting outboards must have the battery cables
connected to a battery whenever the engine is running, even if
started manually, as damage to the charging system could result.
BATTERY CONNECTIONS
Connect a red cable to the positive (+) terminal first and a black
cable to the negative (–) terminal of the battery. Put a red cap on
the positive terminal. When disconnecting battery cables, be sure
to disconnect the black cable first, and then the red cable.
