Mercury 25M User Manual

INSTALLATION
39
6. Press the neck of the shift remote control cable down into the
clamp on the housing of the remote control box. Connect the
terminal eye to the shift arm with the pin and E‑ring. Insert a
grommet, supplied with the remote control box, into the clamp.
37527
a
b
c
d
a - Grommet
b - Shift arm pin
c - E‑ring
d - Shift arm
7. Connect the throttle remote control cable to the throttle arm in
a manner similar to the shift remote control cable.
37526
a
b
c
d
a - Throttle cable
b - Shift cable
c - Throttle arm
d - Shift arm
